Powertec 60 HP 4 Stroke Engine
The Powertrac 60 HP 4-stroke diesel engine features 4 cylinders, a displacement of 3,682 cc to 3,910 cc, and operates at a rated 2,200 RPM. It delivers robust torque up to 250 Nm and powers popular tractor models
- Power Output: 60 HP
- Cylinders: 4 cylinders
- Displacement: 3,682 cc (or up to 3,910 cc depending on variant)
- Rated RPM: 2,200 RPM
- Max Torque: 250 Nm
- Air Filter: Oil bath type or dry type with clogging sensor
- Cooling System: Coolant-cooled / liquid-cooled
Power, Performance and maximum efficiency.
Ultra Low Emission.
High fuel efficiency.
Lightweight and compact.
Proven technology.
EPA Approved, CE and CARB.
Features Powertec 60 HP
Engine type: In-Line Four Cylinder
Displacement: 996 cc (60.8 ci)
Bore & Stroke: 65 x 75 mm (2,56 x 2,95 in)
Compression Ratio: 9.5:1
Prop Shaft Horsepower: 20HP @ 5500rpm
Full Throttle RPM Range: 5000-6000
Fuel/Induction System: EFI
Intake: Single Throttle Valve
Exhaust: Through Proppeler
Cooling: Water / Thermostatic Control
Ignition System: TCI Micro Computer
Alternator Output: 17AMP
Starting System: Electric w/PTT
Lubrication: Wet sump
Engine Oil Capacity: 2,1L/1,9L w/without filter
Gear Ratio: (24:13) 1,85:1
Gear Shift: Forward, Neutral, Reverse
Shaft Length: L= 20 “
Degree of Tilt: 69 °
Degree of Trim: -4* through +20*
Dry Weight: 113kg (249 lbs)
Steering Angle (maximum): 45 ° from center, either direction
