Sale Yamaha 3hp 3BMHS 2 Stroke Outboard Engine Short Shaft

The Yamaha 3hp 3BMHS is a lightweight, portable 2-stroke outboard motor featuring a 70 cc single-cylinder engine, a built-in fuel tank, and manual tiller steering. It uses a 100:1 pre-mix fuel-to-oil ratio and provides forward and neutral gears with 360-degree steering for reverse.

Features:

Type: Hanging
Type of control: Tiller
Boat transom height (cm): 442
Grade: with propeller
Starter Type: Manual
Weight (kg): 16

Specifications:

Engine specifications: 1-cylinder. 2-beat
Displacement (cc): 70
Compression ratio: 6.9
Power (hp): 3
Bore x stroke (mm): 46 x 42
Range max engine speed: 4500-5500 rpm
Ignition system: Cdi
Purge: simultaneous charging
Supply system: 1 carb
Built-in fuel tank (L): 1.3

Max. fuel consumption (l / h): 1.4
Lubrication system: premixing
The proportion of the fuel-oil mixture: 50: 1
Starter: manual
Steering: tiller circular without propeller reverse
Gear shift mechanism: Fn
Gear ratio: 2.08 (27/13)
Exhaust system: over the propeller
Propeller gearing: splined connection
Transom engine height: S 381 mm (17.4 in.)
Dry weight with propeller: 17 kg
Trim and tilt: tame
Cable lanyard to stop the engine: there is
Motor deviation when driving in shallow water: there is
Propeller screw: there is
Tool kit: there is
Emergency start cord: there is
